Data General S1930K-8GP2S-120W

Description

Data General DG-S1930K-8GP2S-120W – Fanless L2+ cloud managed swicth with 8 PoE+ RJ45 gigabit ports and 2 SFP uplink ports

The Data General DG-S1930K-8GP2S-120W is a high-performance Gigabit Ethernet switch designed for seamless integration into business and enterprise networks. It features 8 x 10/100/1000BASE-T PoE+ ports and 2 x 1000BASE-X SFP uplink ports, providing flexible connectivity options. With a PoE budget of 120W, it supports Power over Ethernet (PoE/PoE+) to efficiently power IP cameras, wireless access points, and VoIP phones.

This switch supports advanced network management with features like VLAN segmentation, QoS (Quality of Service), STP/RSTP, ACL filtering, and IEEE 802.1X authentication, enhancing both security and performance. With fanless design, it ensures silent operation, making it perfect for office environments. Cloud-based managementvia Data General Cloud enables remote configuration and monitoring, simplifying network maintenance.

The DG-S1930K-8GP2S-120W is designed to be energy-efficient and compliant with IEEE 802.3az (Energy Efficient Ethernet), reducing operational costs. With strong security protocols, intelligent loop detection, and easy deployment, this switch is an optimal choice for businesses seeking reliable and scalable network solutions.

Technical Specifications:

Performance & Ports:

• Ethernet Ports: 8 x 10/100/1000BASE-T (PoE+)
• SFP Uplink Ports: 2 x 1000BASE-X SFP
• Switching Capacity: 20 Gbps
• Packet Forwarding Rate: 15 Mpps
• MAC Address Table Size: 8K entries
• Jumbo Frame Support: Up to 9,216 bytes

Network Management & Security:

• Cloud Management: Supported via Data General Cloud (TR069)
• VLAN Support: IEEE 802.1Q VLAN (Supports up to 4K VLANs)
• Spanning Tree Protocols: STP, RSTP, MSTP
• QoS (Quality of Service): 8 queues per port, rate limiting, traffic prioritization
• Security Features:
  • ACL filtering
  • DHCP Snooping
  • Port Security
  • IEEE 802.1X authentication
• Loop Detection: RLDP (Rapid Link Detection Protocol)

Power & Environmental:

• Power Supply: Internal
• PoE Budget: 120W
• Power Consumption: ≤ 150W (PoE Model)
• Cooling System: Fanless (Silent Operation)
• Operating Temperature: -5°C to 50°C
• Storage Temperature: -40°C to 70°C
• Operating Humidity: 10% to 90% RH

Physical & Compliance:

• Dimensions (WxDxH): 220 x 150 x 44 mm
• Weight: ≤ 1.1 kg
• Mounting: Rack-mountable (1U)
• Certifications: RoHS, CE, FCC
• Lightning Protection: 6kV (Common Mode)
