Hikvision HWN-4108MH-8P

Description

The Hikvision HWN-4108MH-8P is an advanced 8-channel network video recorder (NVR) designed for hassle-free installation and operation. Equipped with 8 Power over Ethernet (PoE) ports, it eliminates the need for separate power cables for connected IP cameras, streamlining setup and reducing costs. With support for high-definition recordings up to 8MP (4K) and advanced H.265+ compression, it ensures optimal bandwidth usage and extended storage capacity. Compact, efficient, and reliable, this NVR is perfect for small to medium-sized surveillance systems in residential or commercial environments.

Technical Specifications:

• Model: HWN-4108MH-8P
• Channels: 8 channels
• PoE Ports: 8 independent PoE ports (802.3af/at compliant)
• Compression Technology: H.265+, H.265, H.264+, H.264
• Max Recording Resolution: Up to 8MP (4K)
• Storage Capacity: Supports 1 SATA HDD, up to 6TB
• Video Output: HDMI and VGA outputs with up to 4K resolution
• Network Interface: 1 RJ-45 10/100/1000 Mbps Ethernet port
• USB Ports: 1 USB 2.0, 1 USB 3.0
• Power Supply: 48V DC (via external adapter)
• Power Consumption: ≤ 65W (with PoE fully loaded, without HDD)
• Dimensions: 315mm x 240mm x 48mm
• Weight: 2kg (without HDD)
• Operating Temperature: -10°C to 55°C (14°F to 131°F)
• Compatibility: Fully compatible with Hikvision cameras and ONVIF-compliant devices

Key Features:

• 8-channel support with integrated PoE for powering IP cameras directly.
• Advanced H.265+ compression reduces bandwidth and storage needs.
• Supports ultra-high-definition 4K recording for detailed footage.
• 8 PoE ports with up to 30W output per port for flexible camera connections.
• HDMI and VGA outputs for simultaneous video monitoring.
• Remote access via the Hik-Connect app for easy monitoring and control.
