Milesight AM102-868M

Description

The Milesight AM102 LoRaWAN® Indoor Air Quality Sensor is a compact and efficient solution designed to monitor temperature and humidity levels with high accuracy. Featuring an easy-to-read display, the sensor provides real-time environmental data to help optimize indoor conditions and improve comfort in offices, homes, healthcare facilities, and other indoor environments.

With LoRaWAN® technology, the AM102 enables long-range, low-power wireless data transmission, making it ideal for remote monitoring applications. The sleek design and flexible installation options allow for seamless integration into modern smart building solutions.

Technical Specifications

• Model: AM102 LoRaWAN® Indoor Air Quality Sensor
• LoRaWAN® Frequency: 868 MHz (EU868)
• Measured Parameters:
  • Temperature: -10°C to +60°C (±0.3°C accuracy)
  • Humidity: 0% to 100% RH (±3% accuracy)
• Display: High-contrast LCD screen for real-time monitoring
• Connectivity: LoRaWAN® Class A and Class C compatible
• Communication Distance: Up to 10 km (line-of-sight)
• Power Supply: 2 × 3000 mAh Li-SOCL2 batteries
• Battery Life: Up to 5 years (depending on reporting intervals)
• Protection Rating: IP30 (indoor use)
• Material: Industrial-grade plastic housing
• Mounting Options: Wall-mount or desktop placement
• Operating Temperature: -10°C to +60°C
• Humidity: 0–95% RH (non-condensing)
• Dimensions: 118 mm × 85 mm × 27 mm
• Weight: Approx. 200 g

Key Features

• 2-in-1 Environmental Monitoring: Tracks temperature and humidity to ensure optimal indoor conditions.
• Integrated Display: Provides real-time readings with a clear and intuitive LCD screen.
• LoRaWAN® Connectivity: Enables long-range, low-power wireless communication for remote monitoring.
• Energy Efficient: Up to 5 years of battery life for maintenance-free operation.
• Smart Alerts: Configurable threshold notifications for maintaining ideal environments.
• Sleek and Compact Design: Perfect for discreet installation in offices, schools, and homes.
• Flexible Installation: Wall-mount or desktop placement options for easy deployment.
• Reliable Performance: High-accuracy sensors ensure consistent environmental tracking.
