Milesight AM319-868M PN O3

Description

The Milesight AM319 LoRaWAN® Indoor Air Quality Sensor is a cutting-edge 9-in-1 monitoring solution designed to measure and display critical indoor environmental parameters. With the added feature of ozone (O₃) detection, it provides real-time data on air quality, ensuring healthier environments in commercial, healthcare, and industrial spaces.

This sensor leverages LoRaWAN® technology for long-range, low-power connectivity, allowing seamless integration into IoT platforms for continuous monitoring and data-driven insights. The high-contrast LCD screen offers instant readings, while the IP30-rated design makes it suitable for indoor installations.

Technical Specifications

• Model: AM319 LoRaWAN® Indoor Air Quality Sensor with Ozone Detection
• LoRaWAN® Frequency: 868 MHz (EU868)
• Measured Parameters:
  • Temperature: -10°C to +60°C (±0.3°C accuracy)
  • Humidity: 0% to 100% RH (±3% accuracy)
  • CO₂ Concentration: 400 to 5000 ppm (±50 ppm or ±3% accuracy)
  • Formaldehyde (HCHO): 0 to 1.0 mg/m³
  • Ozone (O₃): 0 to 1.0 ppm (±0.01 ppm accuracy)
  • Total Volatile Organic Compounds (TVOC)
  • PM2.5 and PM10 (Particulate Matter)
  • Infrared Motion Sensor (IR)
  • Barometric Pressure
  • Light Intensity
• Display: High-contrast LCD screen for real-time data visualization
• Connectivity: LoRaWAN® Class A and Class C compatible
• Communication Distance: Up to 10 km (line-of-sight)
• Power Supply: 2 × 3000 mAh Li-SOCL2 batteries
• Battery Life: Up to 5 years (depending on reporting intervals)
• Protection Rating: IP30 (indoor use)
• Material: Industrial-grade plastic housing
• Mounting Options: Wall-mount or desktop placement
• Operating Temperature: -10°C to +60°C
• Humidity: 0–95% RH (non-condensing)
• Dimensions: 118 mm × 85 mm × 27 mm
• Weight: Approx. 200 g

Key Features

• 9-in-1 Monitoring Capabilities: Provides comprehensive environmental monitoring, including ozone detection.
• Real-Time Display: High-contrast LCD screen for easy readability of air quality metrics.
• Ozone (O₃) Detection: Tracks ozone levels to ensure safe indoor air quality standards.
• LoRaWAN® Connectivity: Long-range, low-power wireless communication for remote monitoring.
• Configurable Alerts: Set thresholds and receive notifications for unsafe conditions.
• Energy-Efficient Design: Up to 5 years of battery life with minimal maintenance.
• Versatile Applications: Ideal for commercial spaces, healthcare facilities, and industrial sites.
• Easy Installation: Compact design with flexible mounting options for walls or desks.
