Description
The Milesight DS3604 LoRaWAN® IoT E-Ink Display is a high-efficiency, ultra-low power device designed for real-time data visualization in various smart applications. Featuring an easy-to-read electronic ink (E-Ink) screen, it ensures clear and crisp display of critical information such as meeting schedules, inventory levels, sensor data, and more.
With built-in LoRaWAN® technology, the DS3604 enables long-range, low-power communication, making it an ideal solution for smart offices, retail stores, warehouses, and industrial monitoring. The display offers flexible mounting options and is perfect for environments where energy efficiency and remote updates are crucial.
Technical Specifications
- Model: DS3604 LoRaWAN® IoT E-Ink Display
- LoRaWAN® Frequency: 868 MHz (EU868)
- Display Type: E-Ink electronic paper display
- Screen Size: 4.2 inches
- Resolution: 400 × 300 pixels
- Color Mode: Black, white, and red/gray (optional)
- Connectivity: LoRaWAN® Class A compatible
- Communication Distance: Up to 10 km (line-of-sight)
- Power Supply: Built-in replaceable battery
- Battery Life: Up to 5 years (depending on update frequency)
- Protection Rating: IP30 (indoor use)
- Mounting: Wall-mount, desktop, or adhesive mounting
- Operating Temperature: -10°C to +50°C
- Dimensions: 105 mm × 90 mm × 12 mm
- Weight: Approx. 150 g
Key Features
- Ultra-Low Power Consumption: E-Ink technology provides extended battery life for years of operation.
- Real-Time Data Updates: Displays information such as schedules, alerts, and sensor data via LoRaWAN®.
- Long-Range Connectivity: LoRaWAN® enables low-power, long-distance communication.
- High-Resolution Display: Clear and readable from various angles, even in bright conditions.
- Versatile Applications: Ideal for smart offices, conference rooms, warehouses, and industrial monitoring.
- Compact and Lightweight: Easy to install in different environments with multiple mounting options.
- Remote Management: Update and configure display content via IoT platforms remotely.
