Milesight EM300-CL-868M

Description

The Milesight EM300-CL LoRaWAN® Capacitive Level Sensor is a highly accurate and reliable solution designed to measure liquid levels in tanks and containers. Using capacitive sensing technology, the sensor provides real-time data to optimize resource management, prevent overflows, and detect low-level conditions.

With LoRaWAN® technology, the EM300-CL ensures long-range, low-power communication, making it ideal for remote monitoring applications in industries such as agriculture, water management, and fuel storage. Its IP67-rated enclosure guarantees durability and resistance to harsh environmental conditions, ensuring long-term reliability.

Technical Specifications

• Model: EM300-CL LoRaWAN® Capacitive Level Sensor
• LoRaWAN® Frequency: 868 MHz (EU868)
• Measurement Range: 0–200 cm
• Accuracy: ±2% FS
• Resolution: 1 mm
• Connectivity: LoRaWAN® Class A compatible
• Communication Distance: Up to 10 km (line-of-sight)
• Power Supply: Built-in 4000 mAh Li-SOCL2 battery
• Battery Life: Up to 10 years (depending on reporting intervals)
• Protection Rating: IP67 (dustproof and waterproof)
• Material: Industrial-grade plastic housing
• Installation: Surface or tank mounting options available
• Operating Temperature: -30°C to +70°C
• Humidity: 0–95% RH (non-condensing)
• Dimensions: 88 mm × 87 mm × 27 mm
• Weight: Approx. 150 g

Key Features

• High-Precision Measurement: Accurately monitors liquid levels in a wide range of applications.
• LoRaWAN® Connectivity: Enables long-range, low-power wireless communication for remote monitoring.
• Rugged and Durable: IP67-rated enclosure ensures performance in harsh environmental conditions.
• Long Battery Life: Up to 10 years of continuous operation with minimal maintenance.
• Versatile Applications: Ideal for water tanks, wastewater systems, and industrial fluid monitoring.
• Easy Installation: Compact design with flexible mounting options for quick deployment.
