Milesight UG63-868M

Description

The Milesight UG63 Mini LoRaWAN® Gateway is a lightweight and cost-effective gateway designed for indoor IoT applications. Supporting LoRaWAN® technology, the UG63 enables long-range, low-power communication with IoT devices, making it perfect for small-scale deployments in smart buildings, offices, and retail spaces.

With WiFi 4 connectivity and a fast Ethernet port, the UG63 ensures seamless data transmission and easy integration into existing networks. Its compact and modern design is ideal for space-conscious installations, providing reliable and efficient IoT connectivity in a wide range of applications.

Technical Specifications

• Model: UG63 Mini LoRaWAN® Gateway
• Application: Indoor IoT connectivity for small-scale networks
• LoRaWAN® Frequency: 868 MHz
• Connectivity:
  • WiFi 4
  • 1 x Fast Ethernet port (10/100 Mbps)
• Power Supply: USB Type-C (5V DC)
• Enclosure: Compact and lightweight indoor design
• Operating Environment: 0°C to +50°C, 10–90% RH (non-condensing)
• Dimensions: 100 mm x 100 mm x 28 mm
• Weight: 200 g
