Milesight UG67-868M

Description

The Milesight UG67 Outdoor LoRaWAN® Gateway is a powerful solution for enabling wide-area IoT connectivity in challenging environments. Designed with LoRaWAN® technology, the UG67 facilitates long-range, low-power communication with IoT devices. It features a gigabit Ethernet port for high-speed data transfer and WiFi 4 connectivity for versatile backhaul options.

With an IP67-rated enclosure, the UG67 is built to withstand dust, water, and extreme weather conditions, making it ideal for industrial and outdoor applications. External antennas enhance signal strength and reliability, ensuring seamless operation in smart city projects, agricultural monitoring, and remote IoT systems.

Technical Specifications

• Model: UG67 Outdoor LoRaWAN® Gateway
• Application: Wide-area IoT connectivity for industrial and outdoor environments
• LoRaWAN® Frequency: 868 MHz
• Connectivity:
  • LoRaWAN®
  • WiFi 4
  • 1 x Gigabit Ethernet port
• Antenna: External, detachable for LoRaWAN®
• Enclosure Rating: IP67 (dustproof and waterproof)
• Power Supply: PoE or 12V DC
• Operating Environment: -40°C to +70°C, 0–95% RH (non-condensing)
• Dimensions: 225 mm x 165 mm x 50 mm
• Weight: 950 g
