Description
The Ubiquiti UniFi U6-Mesh is a versatile WiFi 6 access point engineered to deliver robust wireless coverage in both indoor and outdoor settings. Featuring 6 spatial streams, it offers an impressive aggregate data rate of up to 5.3 Gbps, ensuring high-speed connectivity for over 300 concurrent devices. Operating on both 2.4 GHz and 5 GHz bands, the U6-Mesh utilizes advanced technologies such as 4×4 MU-MIMO and OFDMA to enhance network efficiency and performance. Its sleek, weather-resistant design (IPX5-rated) allows for flexible installation on walls, poles, or desktops, making it an ideal solution for extending wireless coverage in various environments. Powered via PoE (802.3af), the U6-Mesh integrates seamlessly into existing network infrastructures, simplifying deployment and management through the UniFi Network application.
Technical Specifications:
- WiFi Standards: 802.11a/b/g/n/ac/ax (WiFi 6)
- Frequency Bands: 2.4 GHz and 5 GHz
- MIMO Configuration:
- 2.4 GHz: 2×2 UL MU-MIMO
- 5 GHz: 4×4 DL/UL MU-MIMO
- Maximum Data Rates:
- 2.4 GHz: 573.5 Mbps
- 5 GHz: 4.8 Gbps
- Antenna Gain:
- 2.4 GHz: 3 dBi
- 5 GHz: 5 dBi
- Ethernet Port: 1× 1 Gbps RJ45
- Power Supply: PoE (802.3af)
- Power Consumption: Maximum 11.4W
- Mounting Options: Wall, pole (included); ceiling (optional)
- Operating Temperature: -30°C to 60°C (-22°F to 140°F)
- Operating Humidity: 5% to 95% non-condensing
- Dimensions: Ø48.5 mm × 159.5 mm (Ø1.9 in × 6.28 in)
- Weight: 400 g (0.88 lb)
- Certifications: CE, FCC, IC
The U6-Mesh is an excellent choice for expanding wireless coverage in diverse environments, offering high-speed WiFi 6 performance and flexible deployment options to meet the demands of modern networks.
