Ubiquiti UniFi USW-16-POE

Description

The Ubiquiti UniFi Switch 16 PoE (USW-16-PoE) is a robust, fully managed Layer 2 switch designed to enhance network performance in enterprise settings. Equipped with 16 Gigabit Ethernet ports, it includes 8 auto-sensing 802.3at PoE+ ports, providing a total PoE budget of 42W to power devices such as UniFi Access Points, IP cameras, and VoIP phones. The switch also features 2 SFP ports for fiber uplink connectivity, allowing for seamless integration into larger network infrastructures. Its fanless design ensures silent operation, making it suitable for noise-sensitive environments. Managed through the intuitive UniFi Network Controller, the USW-16-PoE offers comprehensive configuration and monitoring capabilities, making it an ideal choice for scalable network deployments.

Technical Specifications:

• Total Non-Blocking Throughput: 18 Gbps
• Switching Capacity: 36 Gbps
• Forwarding Rate: 26.78 Mpps
• Max. Power Consumption: 18W (Excluding PoE Output)
• Power Method: 100-240VAC, 50/60 Hz, Universal Input
• Power Supply: Internal 60W AC/DC
• Networking Interfaces:
  • 16× 10/100/1000 Mbps RJ45 Ports
  • 2× 1G SFP Ethernet Ports
• PoE Interfaces:
  • Ports 1-8: PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
• PoE Budget: 42W
• Max. PoE Wattage per Port by PSE: 32W
• Operating Temperature: -5°C to 40°C (23°F to 104°F)
• Operating Humidity: 10% to 90% Noncondensing
• Certifications: CE, FCC, IC
• Dimensions: 442.4 mm × 200 mm × 43.7 mm (17.42 in × 7.87 in × 1.72 in)
• Weight:
  • Without Mount: 2.80 kg (6.17 lb)
  • With Mount: 2.89 kg (6.37 lb)

The UniFi Switch 16 PoE is an excellent choice for network administrators seeking a reliable and efficient solution to power and connect multiple devices within a unified network environment.
