Ubiquiti UniFi USW-PRO-24-PoE

Description

The Ubiquiti UniFi Switch Pro 24 PoE (USW-Pro-24-PoE) is a fully managed Layer 3 switch engineered to provide robust switching and routing capabilities for enterprise networks. Equipped with 24 Gigabit Ethernet ports, it includes 16 auto-sensing 802.3af/at PoE+ ports and 8 802.3bt PoE++ ports, offering a substantial total PoE budget of 400W to power a wide range of devices, including high-power PoE equipment. Additionally, the switch features 2 SFP+ ports, supporting 10G uplinks for seamless integration into high-bandwidth network infrastructures. The USW-Pro-24-PoE is designed with near-silent cooling, making it suitable for noise-sensitive environments. Managed via the intuitive UniFi Network Controller, it offers comprehensive configuration and monitoring tools, making it an ideal choice for scalable and efficient network deployments.

Technical Specifications:

• Total Non-Blocking Throughput: 44 Gbps
• Switching Capacity: 88 Gbps
• Forwarding Rate: 65.472 Mpps
• Max. Power Consumption: 50W (Excluding PoE Output)
• Power Method: Universal Input: 100–240V AC, 50/60 Hz
• Power Supply: AC/DC, Internal, 450W
• Total Available PoE: 400W
• PoE Interfaces:
  • Ports 1-16: PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
  • Ports 17-24: PoE++ IEEE 802.3bt (Pair A 1, 2+; 3, 6-; Pair B 4, 5+; 7, 😎
• Max. PoE Wattage per Port by PSE:
  • PoE+: 32W
  • PoE++: 64W
• Networking Interfaces:
  • 24× 10/100/1000 Mbps RJ45 Ports
  • 2× 1/10G SFP+ Ethernet Ports
• Management Interface: Ethernet In-Band
• Operating Temperature: -5°C to 40°C (23°F to 104°F)
• Operating Humidity: 10% to 90% Noncondensing
• Certifications: CE, FCC, IC
• Dimensions: 442.4 mm × 285.4 mm × 43.7 mm (17.42 in × 11.24 in × 1.72 in)
• Weight:
  • Without Mount: 4.30 kg (9.48 lb)
  • With Mount: 4.39 kg (9.68 lb)

The UniFi Switch Pro 24 PoE is an excellent choice for network administrators seeking advanced Layer 3 switching capabilities, substantial PoE power, high-speed uplinks, and near-silent operation, all managed through the user-friendly UniFi Network Controller.
