Ubiquiti USW-Lite-16-PoE

Description

The Ubiquiti UniFi Switch Lite 16 PoE (USW-Lite-16-PoE) is a compact, fully managed Layer 2 switch designed to enhance network performance in small to medium-sized environments. Equipped with 16 Gigabit Ethernet ports, it includes 8 auto-sensing 802.3at PoE+ ports, providing a total PoE budget of 45W to power devices such as UniFi Access Points, IP cameras, and VoIP phones. The switch features a fanless design for silent operation and can be easily managed via the UniFi Network Controller, offering a user-friendly interface for configuration and monitoring. Its compact form factor and included wall-mounting kit allow for flexible installation options, making it a versatile addition to any network setup.

Technical Specifications:

• Total Non-Blocking Line Rate: 16 Gbps
• Max. Power Consumption: 15W (excluding PoE output)
• Power Method: Universal AC input: 100-240V AC
• Power Supply: Internal 60W AC/DC power supply
• Networking Interfaces: 16× 10/100/1000 Mbps Ethernet RJ45
• PoE Interfaces: 8× PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
• Max PoE+ Wattage per Port by PSE: 30W
• PoE Budget: 45W
• Operating Temperature: -15°C to 40°C (5°F to 104°F)
• Operating Humidity: 10% to 90% non-condensing
• Certifications: CE, FCC, IC
• Dimensions: 191.7 mm × 185 mm × 43.7 mm (7.55 in × 7.28 in × 1.72 in)
• Weight: 1.2 kg (2.65 lb)

The UniFi Switch Lite 16 PoE is an excellent choice for network administrators seeking a compact and efficient solution to manage and power multiple devices within a unified network environment.
